It is applicable when data transmission starts. Look at this article for arbitration concept in CAN.ĬSMA/CD is Carrier Sense Multiple Access/Collision Detection. In CAN this feature is introduced by the Arbitration concept. The node having CSMA/CA enabled feature first check the transmission medium status before starting transmission and if BUS is idle(means not is use) then it will start transmission otherwise it will wait for the bus to be idle.
It is applicable before starts of transmission. For more detail go through this article.ĬSMA stands for Carrier Sense multiple Access.This concept is use in transmission media access.if multiple ECUs are connected on sharing same transmission medium to transfer its data then there is possibility of collision and data corruption if multiple nodes start transmission same time.CSMA introduce two concept CSMA/CA and CSMA/CD to avoid this situation.ĬSMA/CA is carrier sense multiple access /collision avoidance. More than 8-byte data will be fragmented in the 8-byte frame as per 15765-2 standard at the transport layer. Physical layer standard used for bit encoding with NRZ line code and data link layer used for error detection, handling, Message receiving/transmission while transport layer protocol 15765-2 used for data packet handling if the data length is greater than 8 byte(<4096 bytes).ĬAN protocol allows only 8-byte data in CAN Frame.
For more detail go through this article.ĬAN Protocol Basically used on Physical layer(11898-2), Data link layer Most popular bit rate is 500 kbps for 100m length. it allows up to 1 Mbps bit rate for 40m wire length. It is an asynchronous serial communication protocol. CAN Stands for Controller Area Network patented by Robert Bosch inġ986 to replace conventional wiring used between ECUs for data sharing between ECUs in vehicle.
